Technical Specification
Chassis | 7-25 Ton GVW Bharat Benz, men, tata, ashok Leyland , Eicher swaraj, mazda or equivalent |
Pump Type | Normal pressure/ multi-pressure (high/low) |
Normal pressure | 1800-2250-3200 LPM @ 7-8.5kg/cm2 |
High pressure | 250 LPM@30-35 kg/cm2 |
PTO | Full Torque drive line |
Water tank (MS) | 3500-6500L |
Foam tank (SS) | 500-1000L |
Foam system | Around the pump (manual/automatic) |
DCP | 2 Nos x 75kgs. with hose reel |
Co2 | 2-4 Nos. 22.5 kgs. |
Mounted equip | Water/foam monitor/Hp hose reel, light mast, elec. operated winch |
Body& lockers | MS/AL/SS and Al Rolling shutters/door type |
